LNG - Gas Naturale Liquefatto
Il gas naturale liquefatto (in inglese LNG – Liquefied natural gas) è un liquido limpido, incolore e non tossico, generato dal raffreddamento del gas naturale a -162 °C (-260 °F) e può essere utilizzato come combustibile per autocarri e per il traffico navale. Il gas naturale, l'idrocarburo con la combustione più pura, è un'importante fonte di energia. Il gas naturale viene raffreddato per diventare liquido, riducendone il volume per una conservazione più facile e sicura, oltre che per il trasporto navale oltremare.
carburante LNG per traffico di trasporto
Title: Shell_LNG_V08_ENG-subs_25mbit_MSTR
Duration: 2:08 minutes
Description:
Shell and the use of LNG in transport.
Shell_LNG_V08_ENG-subs_25mbit_MSTR Transcript
[Background music plays]
The Sound of Shell, a rhythmic instrumental piece featuring synthesised musical effects.
[Voice Over]
My dad was a trucker, and so was his dad.
[Video footage]
Archival footage of trucks approaching on a road, a Shell service station in the background, the Shell pecten signage visible against the cloudy blue sky. Archival black and white side view of the cab of a truck driving in a residential area. Archival black and white close-up, in profile, of a smartly-dressed middle-aged man speaking to someone off-camera.
[Voice Over]
I’ve got diesel running through my veins, you might say. Got a few million miles at the wheel myself. Now, I run my own fleet.
[Video footage]
Close-up of an arm and hand on a steering wheel, traffic passing in the background. The footage turns dark as the driver passes through a tunnel with tunnel lighting; the light returns on side view footage of the driver’s hands on the steering wheel and gear lever respectively. High angle footage of the driver’s hand on the steering wheel in the foreground, while in the background, the white lines of the road flash past in the view through the windscreen.
[Voice Over]
People will always need to transport things, that’s what I say. But my kids, or grandkids, will they be able to enjoy it like I do? You know, the scenery, nature – the way things are going? Something needs to change.
[Video footage]
Low angle mid view of a trucker, seen in profile, turning the steering wheel of his truck, buildings and blue sky visible through his window. Low angle front-side view of a truck and covered trailer approaching on a busy highway, then passing the shot, seen against a snowscape background. Aerial footage of a truck travelling over a bridge that crosses over a dual carriageway below. Bird’s eye view footage of a truck driving along a rural road in semi-darkness, the sky with orange and blue hues. Bird’s eye view footage of a truck driving along a road next to a lake, while rounding a rocky cliff face, snow covered mountains and blue sky visible in the background. Reverse view footage of a truck driving along a narrow road through a vast mountain pass. Low angle close-up of dark smoke coming out of a truck’s exhaust pipe, seen against a pale blue sky.
[Voice Over]
They say LNG is the best alternative fuel over the near future, for long distance transportation.
[Video footage]
Vertically panning close-up of a “Shell LNG” banner. Wide bird’s eye view, cutting to a closer view, of an LNG vessel crossing calm waters, land visible in the background.
[Voice Over]
It’s a cleaner burning alternative to the old diesel, so my LNG truck helps reduce greenhouse gas emissions. It’s a contribution I can make today.
[Video footage]
Close-up of an LNG gas pressure gauge, a hand turning the regulator below the gauge. Close-up of liquid bubbling in a flask in a laboratory environment. Reverse view footage of a laboratory worker, wearing white lab coat, gloves and safety glasses, sliding up a section of glass partitioning in a work area, cutting to a close-up of the workspace and his hand as he pours liquid from one flask into another. Bird’s eye side view footage of a Shell tanker driving on a highway exit, a grassy expanse in the foreground, trees standing tall in the area between the exit and the highway, and power pylons visible in the background against a cloudy blue sky.
[Voice Over]
Of course, every trucker has their favourite make or model. But the big brands are now selling LNG versions, so everyone’s happy.
[Video footage]
Miscellaneous footage of individual truckers, seen in profile, seated in the cabs of their trucks and driving through differing environments. Front view of a truck approaching along a single carriageway running through a mountainous area, seen beneath blue sky; green vegetation lines the road beyond the road’s barrier. Close-up, low angle front-side view of a truck moving along the barriered road, green vegetation visible in the background. Panning low angle view of a truck parked outside a warehouse facility. Mid-view footage of a trucker, seen in profile, seated in his cab, driving his truck, as a Shell branded truck passes in the background.
[Voice Over]
They have pretty similar power, performance and range as diesel does. They have some unexpected benefits, too.
[Video footage]
High angle close-up of a hand on a steering wheel, and the dashboard of the truck behind it. Aerial footage of a truck driving along a single carriageway running through a green landscape, a lake and mountains visible in the background. Bird’s eye view footage of a truck driving in low light along a single carriageway running through a snowscape with sparse green vegetation, the sky with orange and blue hues. Close-up of the truck’s rear door mechanism. Wide view of the rear door of the loaded trailer rolling down to close in an interior warehouse environment, overseen by a man dressed in safety gear.
[Voice Over]
LNG runs quieter, making life better for everyone – especially in cities.
[Video footage]
Wide front view of a truck turning a corner on an urban street to approach a guardhouse entrance with booms, the truck’s headlamps shining brightly against the darkness of night. Aerial footage of a truck driving on an urban street lined with buildings. Low angle footage, from a distance, of a truck passing between city buildings in the background and turning the corner to approach. Wide view footage of a truck approaching, manoeuvring in a paved urban area, tall buildings, blue sky and the occasional tree forming the background.
[Voice Over]
Of course, at first, like anyone, I had my doubts. It all sounds lovely but show me a gas station that sells the stuff.
[Video footage]
Reverse view close-up of a trucker in the cab of his truck, driving along a highway, with other trucks visible on the road in front of him. Close-up of the moving wheels of a truck. Close-up of a hand on a gear lever, changing gears. Wide view of trucks and cars approaching on a busy city highway, with gantry signage, street lamps, green vegetation and pale blue skies forming the background. Close-up of front side panel of a truck’s cab, a Shell service station visible in the background.
[Voice Over]
So they did. In fact, they showed me loads. Shell’s opening LNG stations locally, on major routes and all across Europe – all the time. Refuelling is a bit different, but it isn’t rocket science. It’s simple, safe and speedy.
[Video footage]
Close-up in profile of a trucker in his cab, driving past a Shell LNG service station in the background. Low angle wide view of a Shell LNG service station seen against a brilliant blue sky; a truck pulls in alongside the pumps in the foreground. Mid-view, in profile, of the trucker standing alongside his truck, the fuel flap open; he dons a safety mask, pulls on gloves, removes the cap, cleans the refuelling nozzle with the compressed air gun, connects the nozzle to the fuel tank, pushing the handles forward to engage, and presses the green button to begin refuelling. Low angle close-up, in profile, of the trucker, seen against a background of blue sky. Close-up of vapour coming off of part of the refuelling nozzle. Close-up of part of the truck’s engine, as the driver bends to look at it.
[Voice Over]
And with my Shell Card, I can keep track of all my fuel purchases right across Europe.
[Video footage]
High angle close-up of a hand inserting a Shell LNG Card into the slot for payment. Panning close-up of the changing digits on a fuel pump display screen.
[Voice Over]
But I know what you’re thinking – what’s it all cost? Aren’t they more expensive than diesel? Well, not really.
[Video footage]
Aerial footage of robotic arms assembling equipment on a production line. High angle footage of a robotic arm welding a part. Miscellaneous footage of workers using hand tools to work on parts in a production facility. Time lapse bird’s eye view footage of the cab of a truck being assembled in a production facility as people move about the site. Front view footage of the same cab pulling off from its previous position in the production facility, its headlamps burning brightly.
[Voice Over]
An LNG truck may cost more now, but in the long run, they’re cheaper to run, so you could be better off.
[Video footage]
Aerial view of a truck rounding a hairpin bend in a road running through a mountainous area. Low angle front-side view in close-up of the front of a truck’s cab, seen against a background of blue sky. High angle close-up of a truck’s fuel tank and spinning wheels, with vehicles flashing past in the foreground.
[Video footage]
More footage of a trucker connecting a refuelling nozzle to his truck’s fuel tank, pushing the handles forward to engage. Close-up of a gloved hand pressing the start button to begin refuelling. Close-up of the changing digits on a fuel pump display screen. Close-up of the trucker pulling the handles back to disengage the refuelling nozzle from his truck’s fuel tank, clouds of vapour releasing at the same time.
[Voice Over]
I’ve made the right decision, I’ve chosen LNG.
[Video footage]
Low-angle footage of a trucker’s hands on the steering wheel of his truck, as seen through the driver’s window, the shot panning down to the wording “Shell LNG Fuelling the Future” painted on the side of the truck.
[Audio]
Shell jingle
[Graphic]
Shell Pecten centred on a white background with text displaying below.
[Text displays]
© Shell International Limited 2018
Il rifornimento del LNG è facile
Il tempo di rifornimento del LNG è paragonabile a quello del gasolio. Nel video potete vedere con quanta facilita si effettua il rifornimento del carburante.
Istruzioni per il rifornimento del LNG nelle stazioni di servizio Shell per veicoli che recuperano i vapori tramite il dosatore del LNG (ad es. VOLVO)
Title: LNG Refueling instructions at a shell station, for vehicles with vapour return via the LNG nozzle (for example Volvo)
Duration: 5:37 minutes
Description:
Video outlines the procedures that need to be followed when refueling an LMG truck, with vapour return via the LNG-nozzle, at a Shell station.
Video outlines the procedures that need to be followed when refueling an LMG truck, with vapour return via the LNG-nozzle, at a shell station. At first the required pieces of personal protection equipment are explained. After this, the safety and emergency procedures at the Shell station are explained.
The video shows how to properly connect the truck to the dispenser, how and when to use the vapour return valve, how to start an LNG transaction and fueling process, how to properly disconnect the truck from the dispenser and how to end the LNG transaction and leave the Shell station.
LNG Refueling instructions at a shell station, for vehicles with vapour return via the LNG nozzle (for example Volvo)Transcript
[Video footage]
A Shell LNG fuelling station is shown from above. Then an LNG tank at the station is shown in more detail.
[Voice-over plays]
It’s explained that LNG refuelling is fast, safe and easy but that safety precautions and procedures should be taken.
[Background music plays]
Soft bright background music plays throughout the video
[Text displays]
LNG Refueling instructions at a shell station
for vehicles with vapour return via the LNG nozzle (for example Volvo)
[Video footage]
A truck pulls up at the Shell LNG station. After that a connected LNG nozzle with cold vapour coming off of it is show.
[Text displays]
Caution
Exposure to LNG can cause severe cold burns or frostbite symptoms.
You must wear personal protective equipment (PPE)
[Voice-over plays]
The risks of exposure to LNG are explained along with the need for personal protective equipment. Various items of personal protective equipment are named.
[Video footage]
The truck driver wearing the required personal protective equipment, closed shoes, long trousers, cryogenic gloves, long sleeves and a visor, is shown. After that, a sign at the Shell station with safety regulations is show.
[Voice-over plays]
Safety regulations at the Shell station are explained.
[Video footage]
A truck pulls up at the Shell LNG station. After that the station’s emergency stop, intercom, fire extinguisher and assembly point are show. The sign with safety regulations is shown once more together with the Station’s safety features.
[Voice-over plays]
Emergency procedures at the station is explained
[Text displays]
Warning
In case of emergency
-Press shutdown button
-Evacuate the area
-Notify staff via intercom
[Video footage]
The truck driver uses the intercom at the Shell station.
[Voice-over plays]
It is explained when to use the intercom for immediate staff assistance.
[Voice-over plays]
Instructions are given to engage the truck’s parking brake and turn off the engine.
[Text displays]
Step 1
Park vehicle, engage parking brake, turn off engine
[Video footage]
The truck driver puts his truck in park, the parking break lever inside the truck is shown. After that, the ignition key is shown to be turned to the off position.
[Voice-over plays]
Voice over explains what a red and green light on a dispenser mean.
[Text displays]
Step 2
Check dispenser availability
[Video footage]
The truck driver gets out of his truck. At first a dispenser with a red light, below the counter display, is shown. After that a dispenser with a green light is shown
[Voice-over plays]
Instructions to put on Personal Protective Equipment are given.
[Text displays]
Step 3
Put on Personal Protective Equipment (PPE)
[Video footage]
The truck driver opens a storage bin on the side of his truck and takes out his Personal Protective Equipment.
[Voice-over plays]
Instructions to put on Personal Protective Equipment are given.
[Text displays]
Step 4
Connect earthing cable
[Video footage]
The earthing cable that’s stored on the side of the LNG nozzle bay is shown. The truck driver connects the earthing cable to the earthing point on his truck’s tank. A truck symbol appearing on the dispenser’s display is shown along with a green light turning on on the side of the LNG nozzle bay.
[Voice-over plays]
Instructions to remove the truck’s tank cap are given. It is explained how to properly clean the LNG receptacle with compressed air before usage.
[Text displays]
Step 5
Remove tank cap, clean LNG receptacle
[Video footage]
The truck’s tank cap is removed by the driver. The driver then presses a black button labeled “perslucht – compressed air”. The driver then blows air on the LNG receptacle on his truck.
[Voice-over plays]
Instructions are given on how to properly clean and connect the LNG nozzle. It’s explained why any potential water or dirt needs to be removed from the receptacle. It is then explained how to use the red safety button on the receptacle and attach the nozzle to the truck.
[Text displays]
Step 6
Clean and connect LNG nozzle
[Video footage]
The driver takes the LNG nozzle out of the LNG nozzle bay and blows air on it using the air gun. After a few seconds the driver stores away the air gun and takes the LNG nozzle towards his truck. The truck driver presses the red safety button on top of the LNG nozzle. He then places the nozzle on the receptacle and pushes the handles on the nozzle towards his truck.
[Text displays]
Caution
DO NOT use excessive force
This can cause damage to receptacle or nozzle and may lead to LNG spillage
[Voice-over plays]
A warning is given not to use excessive force when attaching the nozzle, as it can damage both the nozzle and receptacle.
[Voice-over plays]
Instructions are given to use the truck tank’s pressure gauge to check the tank’s pressure. The information is given that if the pressure is over 10 bar it needs to be reduced.
[Text displays]
Step 7
Check tank pressure
[Video footage]
The truck’s tank pressure gauge is shown. The gauge reads 12 bar.
[Voice-over plays]
Instructions are given on how to reduce the tank’s pressure to below 10 bar by using the vapour return valve. Instructions are given to keep the LNG nozzle attached to the truck after the vapour return procedure is done.
[Text displays]
Step 7a
Vapour return procedure (if necessary)
[Video footage]
The truck driver opens the vapour return valve by using a lever above the receptacle on his truck’s tank. The tank pressure gauge drops to below 10 bar, after which the truck driver closes the return valve again using the same lever. After that, the LNG nozzle is shown to be still attached to the receptacle.
[Voice-over plays]
It’s explained that the blue button on the dispenser is for extra cold LNG
[Text displays]
Step new
For Volvo-only: select “Extra cold LNG” (if available at station)
[Video footage]
A blue button on the LNG dispenser is shown.
[Voice-over plays]
The instruction is given to start the LNG transaction by using your Shell LNG card at the payment terminal located near the dispensers. It’s explained that a transaction can only be started with an authorised Shell LNG card.
[Text displays]
Step 8
Start transaction at payment terminal
[Video footage]
The driver walks to the payment terminal and inserts his Shell LNG card. He then enters the required information on the screen of the payment terminal.
[Voice-over plays]
It’s explained that the LNG refuelling process can be started by pressing and holding the green button and that refuelling stops when the button is released. It is also explained that it’s normal for ice crystals or vapour to form during refuelling
[Text displays]
Step 9
Press and hold START button
[Video footage]
The truck driver presses and holds the green button on the LNG dispenser. A new symbol appears on the dispenser’s display and the numbers on the display start to count up. After that, the LNG nozzle is shown whilst ice forms on it and cold vapour comes off of it.
[Voice-over plays]
It’s explained that the refuelling automatically stops when the truck’s tank is full.
[Text displays]
Step 10
Pump stops when tank is full
[Video footage]
The dispenser’s display shows the word “end”. The truck driver releases the green button.
[Voice-over plays]
Instructions are given on how to disconnect the LNG nozzle
[Text displays]
Step 11
Disconnect the LNG nozzle
[Video footage]
The truck driver pulls back the levers on the LNG nozzle, pushes the red button on the nozzle and removes the nozzle from the truck.
[Voice-over plays]
Instructions are given on how to properly clean and stow away the LNG nozzle after use.
[Text displays]
Step 12
Clean the LNG nozzle
[Video footage]
The truck driver takes the air gun from the side of the LNG nozzle bay and blows air on the LNG nozzle. After that the driver places the nozzle back in the holder on the side of the dispenser.
[Voice-over plays]
Instructions are given to clean the LNG receptacle using the air gun and to replace the tank cap.
[Text displays]
Step 13
Place tank cap back
[Video footage]
The truck driver uses the air gun to blow air onto the LNG receptacle on his truck. He then puts the tank cap on the receptacle.
[Voice-over plays]
Instructions are given to remove and properly store the earthing cable.
[Text displays]
Step 14
Disconnect the earthing cable
[Video footage]
The truck driver removes the earthing cable from his truck’s tank. He then stores the cable by clamping it to the designated spot on the side of the LNG nozzle bay.
[Voice-over plays]
It’s explained that Personal Protection Equipment can now be taken off and stored away.
[Text displays]
Step 15
Remover Personal Protective Equipment (PPE)
[Video footage]
The truck driver takes of his gloves and visor and stores them in the storage bin on the side of his truck.
[Voice-over plays]
Instructions are given to complete the transaction at the payment terminal
[Text displays]
Step 16
Finish transaction at payment terminal
[Video footage]
The truck driver walks towards the payment terminal
[Voice-over plays]
Precautions that need to be taken before starting the truck are given.
[Text displays]
Caution
Before starting your vehicle please ensure
- Nozzles, hoses and earthing disconnected and stowed
- Tank cap properly attached
- Vehicle and dispenser free of leaks
[Video footage]
The truck driver climbs back into his truck and drives out of the Shell station.
[Voice-over plays]
It’s explained that different stations may have minor design differences and that site-specific instructions are always on display.
[Animated sequence]
